Plane machine

Product Description:

◆ The planing blades are all imported from Germany and imported Luxembourg blades. They do not grind super hard blade on all sides, which are convenient to use.

◆ Spiral planer combination of double -sand frame combination shaving is formed at one time.

◆ The unique design of the front and rear pressure boots can really do not scoop up.

◆ conveyor belt: seven layers of overlapping Best transmission.

◆ Transfer platform: 10 cm thick marble.

◆ Pure copper core energy -saving motor.

◆ body: National standard steel welding CNC Dragon Gate milling treatment, sheet metal laser under -plastic spraying.

Product Details

SpecificationsB-R-RP630B-R-RP1000B-R-RP1300
Processing width mm<630<1000<1300
Processing thickness mm2-1102-1102-110
Machining board length mm>400>400>400
Band size mm650*19301030*19301030*2200
Plane motor KW111530
First sand motor power KW111530
Second sand motor power KW7.51122
Transfer motor power KW1.52.24
Lift motor power KW0.370.370.55
working pressure Mpa0.50.60.6
transfer speed m/s5--255--255--25
Vacuum m3/h500050005000
Dimensions mm1600*1250*21501600*1450*21502700*2200*2150
weight Kg260034004200
